| MC-405C(4면) | |||||||
|---|---|---|---|---|---|---|---|
| 4.735m/7.695m Boom | 10.655m Boom | 13.565m Boom | 16.475m Boom | ||||
| 작업반경(m) | 정격하중(kg) | 작업반경(m) | 정격하중(kg) | 작업반경(m) | 정격하중(kg) | 작업반경(m) | 정격하중(kg) |
| 2.7 or less | 3,830 | 3.5 | 3,030 | 4.0 | 2,230 | 5.0 | 1,130 |
| 3.5 | 3,030 | 4.0 | 2,580 | 4.5 | 1930 | 5.5 | 980 |
| 4.0 | 2580 | 5.0 | 2,030 | 5.0 | 1,730 | 6.0 | 910 |
| 5.0 | 2,030 | 6.0 | 1,680 | 6.0 | 1400 | 7.0 | 460 |
| 6.0 | 1,380 | 8.0 | 1,130 | 7.0 | 1160 | 8.0 | 650 |
| 7.0 | 1,330 | 8.0 | 1,130 | 8.0 | 1,030 | 9.0 | 600 |
| 7.25 | 1,330 | 9.0 | 880 | 9.0 | 930 | 10.0 | 550 |
| 10.2 | 580 | 10.0 | 830 | 11.0 | 490 | ||
| 11.0 | 690 | 12.0 | 440 | ||||
| 12.0 | 530 | 13.0 | 380 | ||||
| 13.1 | 430 | 14.0 | 320 | ||||
| 15.0 | 260 | ||||||
| 16.0 | 210 | ||||||
|
|||||||||
